CC1010
SWRS047
Page 119 of 152
FREND (0xEE) - Front End Control Register
Bit
Name
R/W
Reset value
Description
7:6
-
R/W
0
Reserved, should always be written 0
5
BUF_CURRENT
R/W
0
Control of current in the LNA_FOLLOWER
0 : 520uA, use for f<500 MHz
1 : 690uA, use for f>500 MHz
4:3
LNA_CURRENT(1:0)
R/W
00
Control of current in LNA
00 : 0.8mA
01 : 1.4mA, use for f<500 MHz
10 : 1.8mA, use for f>500 MHz
11 : 2.2mA
2
IF_EXTERNAL
R/W
0
Controls where the output from the mixer
goes:
0: To internal IF filter and demodulator
1: To the
AD2(RSSI/IF) pin for external
filtering and demodulation
1
RSSI
R/W
0
0: RSSI output disconnected from
AD2(RSSI/IF)pin
1: RSSI output connected to
AD2(RSSI/IF)pin
0
-
R/W
0
Reserved, should always be written 0
