 2022 Microchip Technology Inc. and its subsidiaries

DS00002329E-page 137

KSZ9567R

5.2.1.5

Port Interrupt Status Register

These registers provide interrupt status for the individual ports. these interrupts are enabled in the Port Interrupt Mask

5.2.1.6

Port Interrupt Mask Register

This register enables the interrupts in the Port Interrupt Status Register.

Address:

0xN01B

Port N: 1-7

Size:

8 bits

Bits

Description

Type

Default

7:3

RESERVED

0000_00b

PTP Interrupt Status

Applies only to PHY ports, not MAC port(s). Refer to the Port PTP Timestamp

Interrupt Status Register for individual PTP interrupts.

0 = No interrupt

1 = Interrupt detected

PHY Interrupt Status

Applies only to PHY ports, not MAC port(s). Refer to the Port Interrupt

Control / Status Register for individual PHY interrupts.

0 = No interrupt

1 = Interrupt detected

ACL Interrupt Status

ACL interrupts can be generated by configuring an entry in the ACL Table for

counter mode. All ports have an ACL Table.

To clear this bit, toggle the ACL Interrupt Mask bit in the Port Interrupt Mask

0 = No interrupt

1 = Interrupt detected

Address:

0xN01F

Port N: 1-7

Size:

8 bits

Bits

Description

Type

Default

7:3

RESERVED

0000_00b

PTP Interrupt Enable

Applies only to PHY ports. Refer to the Port PTP Timestamp Interrupt Enable

0 = Interrupt enabled

1 = Interrupt disabled

R/W

PHY Interrupt Enable

Applies only to PHY ports.

0 = Interrupt enabled

1 = Interrupt disabled

R/W
