Specifications by Frequency

Description

F1

F2

F3

F4

F5

Units

Range

DC to 4

4 to 7.5

GHz

VSWR, Max

1.25:1

1.45:1

.

Mechanical Specifications

Size

Length

5.55 in [140.97 mm]

Width/Diameter

2.65 in [67.31 mm]

Height

2.65 in [67.31 mm]

.

Weight

1.65 lbs [748.43 g]

Body Material and Plating

Black Anodized Aluminum Heatsink

Configuration

Design

Fixed, Bidirectional

Package Style

Connectorized Module

Connectors

Description

Connector 1

Connector 2

Type

7/16 DIN Male

7/16 DIN Female

Contact Material and Plating

Beryllium Copper

Beryllium Copper

Hex Size

1 1/4 in.

Torque

18.417 ft-lbs 24.97 Nm

Body Material and Plating

Brass

Brass

.

Environmental Specifications

Temperature

Operating Range

-65 to +125 deg C

RoHS Compliant

REACH Compliant

12/17/2015

Plotted and Other Data

Notes:

PE7041-40 REV 1.1

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: 40 dB Fixed Attenuator, 7/16 DIN Male to 7/16 DIN Female Black Anodized Aluminum Heat-

sink Body Rated to 25 Watts Up to 7.5 GHz

PE7041-40

RF Fixed Attenuators Technical Data Sheet

PE7041-40

40 dB Fixed Attenuator, 7/16 DIN Male to

7/16 DIN Female Black Anodized Aluminum Heatsink

Body Rated to 25 Watts Up to 7.5 GHz
