Data Sheet

ADL5534

Rev. B | Page 3 of 16

SPECIFICATIONS

VPOS = 5 V and TA = 25°C, unless otherwise noted.

Table 1.

Parameter

Conditions

Min

Typ

Max

Unit

OVERALL FUNCTION

Frequency Range

500

MHz

Gain (S21)

190 MHz

20.4

Input Return Loss (S11)

190 MHz

−18.0

Output Return Loss (S22)

190 MHz

−29.0

Reverse Isolation (S12)

190 MHz

−23.0

FREQUENCY = 70 MHz

Gain

21.0

vs. Frequency

±5 MHz

±0.04

vs. Temperature

−40°C ≤ TA ≤ +85°C

±0.20

vs. Supply

4.75 V to 5.25 V

±0.20

Output 1 dB Compression Point

20.4

dBm

Output Third-Order Intercept

∆f = 1 MHz, output power (POUT) = 0 dBm per tone

40.0

dBm

Noise Figure

2.5

Device-to-Device Isolation

Measured at output with input applied to alternate device

−46.0

FREQUENCY = 190 MHz

Gain

19.5

20.4

vs. Frequency

±50 MHz

±0.15

vs. Temperature

−40°C ≤ TA ≤ +85°C

±0.20

vs. Supply

4.75 V to 5.25 V

±0.17

Output 1 dB Compression Point

20.6

dBm

Output Third-Order Intercept

∆f = 1 MHz, output power (POUT) = 0 dBm per tone

39.0

dBm

Noise Figure

2.7

Device-to-Device Isolation

Measured at output with input applied to an alternate device

−38.0

FREQUENCY = 380 MHz

Gain

19.0

19.8

20.5

vs. Frequency

±50 MHz

±0.18

vs. Temperature

−40°C ≤ TA ≤ +85°C

±0.22

vs. Supply

4.75 V to 5.25 V

±0.16

Output 1 dB Compression Point

20.4

dBm

Output Third-Order Intercept

∆f = 1 MHz, output power (POUT) = 0 dBm per tone

36.0

dBm

Noise Figure

3.0

Device-to-Device Isolation

Measured at output with input applied to an alternate device

−34.0

POWER INTERFACE

RFOUT1, RFOUT2 pins

Supply Voltage

4.75

5.25

Supply Current

Per amplifier

110

vs. Temperature

−40°C ≤ TA ≤ +85°C

±15

Power Dissipation

0.5
