ADRF6520

Data Sheet

Rev. 0 | Page 6 of 29

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltages, VPS, VPSD

3.6 V

ENBL, LE, CLK, DATA, SDIO

VPSD + 0.5 V

INP1, INM1, INP2, INM2,

VPS + 0.5 V

OPP1, OPM1, OPP2, OPM2

VPS + 0.5 V

OFS1, OFS2, VRMS

VPS + 0.5 V

VGN1, VGN2

VPS + 0.5 V

Internal Power Dissipation

1.53 W

Maximum Junction Temperature

125°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Lead Temperature (Soldering 60 sec)

300°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

Thermal performance is directly linked to printed circuit board

(PCB) design and operating environment. Careful attention to

PCB thermal design is required.

Table 3. Thermal Resistance

Package Type

θJA1

θJC2

Unit

CP-32-12

29.4

2.0

°C/W

Based on simulation with JEDEC standard JESD51, using a 2S2P board.

Based on simulation with JEDEC standard JESD51, using a 1S0P board.

ESD CAUTION
