VCXO2HV 1/4

v1.0

VCXO2HV

High Frequency VCXO with Military

Temperature Range

Military temperature range -55+125°C

Low noise - fundamental crystal

High shock & vibration resistance

Optional tinned pads (Ag/Cu/Zn)

Option Code

CONFIGURABLE OPTIONS

Parameter

Frequency

Absolute pulling range (max)

see note below

Any

±130ppm over -40 to +85°C

B

±110ppm over -55 to +125°C

C

Terminations

Gold plated pads

Tinned Ag/Cu/Zn/

T

APR is inclusive of calibration @ 25°C, operating temperature range, supply voltage change, load change and

ageing (1 year)

*
