GT25 Series ● Interface Connector

● Housing（Pre-assembled retainer）

■ F Connector

2.7

Part No.

HRS No.

Color

Material

No. of Contacts

A Dimension

Packaging

RoHS

GT25-8DS-HU/R

775-0059-3

Housing

：Black

Retainer

：Dark

Gray

Housing

：PPE

Retainer

：PBT

811

YES

GT25-12DS-HU/R

775-0062-8

PBT

15.4

GT25-24DS-HU/R

775-0046-1

Housing

：PPE

Retainer

：PBT

28.6

GT25-32DS-HU/R

775-0044-6

37.4

Note 1 : Pre-assembled retainer into housing body

Note 2 : After insert assembled contact, retainer has to be pushed-in correct position

Note 3 : Available to purchase housing and retainer separately for repair.

Part No.

HRS No.

Material

Plating

Conductor Size (AWG)

Outer Diameter

Packaging

RoHS

GT25H-2024SCF

775-0039-6

Copper palloy

Tin plating

20 to 22 AWG

φ1.0 to 1.7

10,000 pcs/reel

YES

GT25HB-2428SCF

775-0070-6

24 to 28 AWG

φ0.5 to 1.0

1.4

1.9

■ F Terminal
