41

BSC Duplex connector assemblies.

Note 1: The "L" within the Product Number indicates the length of the cable. Please specify "L" in mm.

Note 2: Please contact us if you have any requests. HIROSE will offer excellent solutions to meet your requirements.

BMounting Dimensions

Note 1: * indicates cable diameter:

2= Ø2mm diameter

3= Ø3mm diameter

Note 2: # indicates polishing type:

1= PC polishing

2= AdPC polishing

Part Number

CL No.

Fiber cable type

Polishing type

Cable Diameter

HSCF-SP2PP-F3Q-L

HSCH-SP2PP-F3Q-L

HSCF-SP2PP-F3QW-L

HSCH-SP2PP-F3QW-L

HSCF-SP2PP-F3A-L

HSCH-SP2PP-F3A-L

HSCF-SP2PP-F3AW-L

HSCH-SP2PP-F3AW-L

HSCF-ASP2PP-F3Q-L

HSCH-ASP2PP-F3Q-L

HSCF-ASP2PP-F3QW-L

HSCH-ASP2PP-F3QW-L

HSCF-ASP2PP-F3A-L

HSCH-ASP2PP-F3A-L

HSCF-ASP2PP-F3AW-L

HSCH-ASP2PP-F3AW-L

HSCF-SP2PP-F3P-L

HSCH-SP2PP-F3P-L

HSCF-SP2PP-F3PW-L

HSCH-SP2PP-F3PW-L

HSCF-SP2PP-F3B-L

HSCH-SP2PP-F3B-L

HSCF-SP2PP-F3BW-L

HSCH-SP2PP-F3BW-L

704-4031-9

-------

-------

-------

-------

-------

704-4013-7

-------

-------

-------

-------

-------

-------

-------

-------

704-4018-0

704-4038-8

-------

-------

-------

-------

-------

704-4039-0

-------

SM-9.5/125

GI-50/125

PC

AdPC

PC

Ø2mm

Ø2mm Zip cord

Ø3mm

Ø3mm Zip cord

Ø2mm

Ø2mm Zip cord

Ø3mm

Ø3mm Zip cord

Ø2mm

Ø2mm Zip cord

Ø3mm

Ø3mm Zip cord

Plug

Panel

Adapter

Plug

HSC-PH

*-A4

HSC-PH0.9-E

#

HSC-PH

*-A4

HSC-PH0.9-E

#

HSC-PH

*-E#

HSCF-PH

*-B#(P)

HSC-PH

*-E#

HSCH-2PH

*-B#(P)

HSCF-2A(P)

HSCF-2A-D(P)

Combination

Dimensions

Adapter

Housing

a

b

c

d

e

f

58

28

15.2

53.4

23.4

10.6

39.5

28

15.2

34.9

23.4

10.6

36

26

15.2

31.4

21.4

10.6

HSCH-2A(P)

HSCH-2A-D(P)

HSCH-2A1(P)

Combination

Dimensions

Adapter

Housing

a

b

c

d

e

f

58

28

15.2

53.4

23.4

10.6

39.5

28

15.2

34.9

23.4

10.6

36

26

15.2

31.4

21.4

10.6

Unit: mm

<F Type>

<H Type>
