AD9577
Data Sheet
Rev. A | Page 22 of 44
TYPICAL OUTPUT SIGNAL
5ns/DIV
Figure 20 Typical LVPECL Differential Output Trace, 156.25 MHz
5ns/DIV
Figure 21. Typical LVDS Differential Output Trace, 156.25 MHz
1ns/DIV
Figure 22. Typical CMOS Output Trace, 200MHz
1ns/DIV
Figure 23. Typical LVPECL Differential Output Trace, 625 MHz
1ns/DIV
Figure 24. Typical LVDS Differential Output Trace, 625 MHz
10ns/DIV
Figure 25. Typical REFOUT Output Trace, 25 MHz
