AD5624/AD5664

Data Sheet

Rev. A | Page 6 of 23

ABSOLUTE MAXIMUM RATINGS

TA = 25°C, unless otherwise noted.

Table 5.

Parameter

Rating

VDD to GND

−0.3 V to +7 V

VOUT to GND

−0.3 V to VDD + 0.3 V

VREF to GND

−0.3 V to VDD + 0.3 V

Digital Input Voltage to GND

−0.3 V to VDD + 0.3 V

Operating Temperature Range

Industrial (A Grade, B Grade)

−40°C to +105°C

Storage Temperature Range

−65°C to +150°C

Junction Temperature (TJ max)

150°C

Power Dissipation

(TJ max − TA)/θJA

LFCSP_WD Package (4-Layer Board)

θJA Thermal Impedance

61°C/W

MSOP Package (4-Layer Board)

θJA Thermal Impedance

142°C/W

θJC Thermal Impedance

43.7°C/W

Reflow Soldering Peak Temperature

Pb-Free

260°C ± 5°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

ESD CAUTION
