SSM2529

Data Sheet

Rev. 0 | Page 8 of 52

ABSOLUTE MAXIMUM RATINGS

Absolute maximum ratings apply at 25°C, unless otherwise noted.

Table 6.

Parameter

Rating

SPKVDD Supply Voltage

−0.3 V to +5.5 V

DVDD Supply Voltage

−0.3 V to +1.98 V

Input Voltage (Signal Source)

−0.3 V to +3.6 V

ESD Susceptibility

4 kV

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +85°C

Junction Temperature Range

−65°C to +165°C

Lead Temperature (Soldering, 60 sec)

300°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 7. Thermal Resistance

Package Type

Unit

16-Ball, 1.92 mm × 1.94 mm WLCSP

56.1

°C/W

ESD CAUTION
