Crimp contact - CK4,0-ED-1,50BU AG - 1663271

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://download.phoenixcontact.com)

Turned 4.0 crimp contact, individual female contact, core diameter 1.50 mm², silver-plated

Key commercial data

Packing unit

1 pc

GTIN

Weight per Piece (excluding packing)

2.74 GRM

Custom tariff number

85366990

Country of origin

Germany

Technical data

Electrical characteristics

Note

For HC-M-3 modules

Ambient conditions

Ambient temperature (operation)

-40 °C ... 125 °C

Mechanical characteristics

Conductor cross section

1.5 mm²

Connection cross section AWG

16

Stripping length of the individual wire

9 mm (9.6 mm (4 - 6 mm²)/18 mm (10 mm²))

Insertion/withdrawal cycles

≥ 500

General

Type

Individual female contact

Series

HC-M-03

Connection method

Crimp connection
