Features 特征

SMB

●

For surface mounted applications 适用于表面贴装

●

Low reverse leakage current 反向漏电流小

RoHS

●

Low forward voltage drop 正向压降低

COMPLIANT

●

High surge capacity 耐浪涌能力高

●

Meet UL flammability classification 94V-0 符合UL 94V-0阻燃等级

Mechanical Data 外观信息

●

Case: JEDEC SMB molded plastic 封装：SMB塑封

●

Polarity: Color band denotes cathode 极性：阴极色环标识

●

Mounting position: Any 安装位置：不限

Applications 应用

●

For use in low voltage, high frequency inverters,

polarity protection applications

应用于低压，高频变换器，极性保护

Maximum Ratings and Electrical Characteristics 最大额定值及电气特性

Rating at 25℃ ambient temperature unless otherwise specified. 环境温度25℃，除非特别说明。

Single phase, half wave, 60Hz, resistive or inductive load. 单相半波， 60Hz， 阻性或感性负载。

For capacitive load, derate current by 20%. 对于电容性负载，降低20%的额定电流。

Characteristics

特性

Symbol

符号

S3AB

S3BB

S3DB

S3GB

S3JB

S3KB

S3MB

Unit

单位

Maximum Repetitive Peak Reverse Voltage

最大重复峰值反向电压

Maximum RMS Voltage 最大有效反向电压

35

70

140

280

420

560

700

V

Maximum DC Blocking Voltage 最大直流阻断电压

50

100

200

400

600

800

1000

V

最大正向平均整流电流

Peak Forward Surge Current, 8.3mS Single Half Sine-Wave,

Superimposed on Rated Load (JEDEC Method)

8.3mS单一正弦半波叠加在额定负载上的浪涌能力（JEDEC方法）

I

I

A

Peak Forward Voltage at 3.0A DC (Note1)

在3.0 A 电流下的正向峰值电压（备注1）

在额定直流电压下的最大反向直流电流

Typical Junction Capacitance (Note 2) 典型结电容

pF

Typical Thermal Resistance Junction to Lead

结到引线的典型热阻值

Typical Thermal Resistance Junction to Ambient

结到环境的典型热阻值

Operating Junction Temperature Range 结温工作范围

℃

Storage Temperature Range 储存温度范围

℃

Notes: 1. 300uS pulse width, 2%duty cycle. 300uS脉宽，2%占空比。

2. Measured at 1.0 MHz and applied reverse voltage of 4.0V DC. 在1MHz，4.0V条件下测试

3. The typical data above is for reference only . 典型值仅供参考。

S3*B-13-00-00

Rev. 9, 30-Jan-2019

℃/W

℃/W

-55 to+150

Forward Current - 3.0 Amperes

正向电流 3.0A

250

10

40

800

3.0

100

A

600

400

-55 to+150

www.hygroup.com.tw

S3AB THRU S3MB

uA

100

A

V

5.0

50

Pb

Surface Mount Glass Passivated Rectifiers

贴片式玻璃钝化整流器

封装外观尺寸单位英寸（毫米）

50

Package Outline Dimensions in Inches (Millimeters)

Reverse Voltage - 50 to 1000Volts

反向电压 50-1000V

1.1

200

1000

V

41.5
