Technical Data 4132

Effective April 2016

Supersedes March 2007

DR1030

Shielded power inductors

Description

•

Shielded drum core

•

Inductance range from 1.1 μH to 155 μH

•

Current range from 0.68 A to 9.5 A

•

10.5 mm x 10.3 mm footprint surface mount

package in a 3.0 mm height

•

Ferrite core material

•

Halogen free, lead free, RoHS compliant

Applications

•

LED/LCD backlighting

•

High definition televisions (HDTV)

•

Server and desktop power supplies

•

Portable electronics

•

Notebook and laptop regulators

•

Graphics cards and battery powered systems

•

Point-of-load (POL) modules

•

Printers and peripherals

Environmental Data

•

Storage temperature range (Component):

-40 °C to +125 °C

•

Operating temperature range: -40 °C to +125 °C

(ambient plus self-temperature rise)

•

Solder reflow temperature: J-STD-020D

compliant

Pb

HALOGEN

HF

FREE
