7

CLD-CT1157.001

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300

Fax: +1.919.313.5778

www.cree.com/ledlamps

Copyright©2009Cree,Inc.Allrightsreserved.Theinformationinthisdocumentissubjecttochangewithoutnotice.Cree,the

CreelogoandScreenMasterareregisteredtrademarksofCree,Inc.

Mechanical Dimensions

Alldimensionsareinmm.Toleranceis±0.25mmunlessotherwisenoted.

An epoxy meniscus may extend about 1.5 mm down the leads.

Burraroundbottomofepoxymaybe0.5mmmax.

Notes

RoHS Compliance

Thelevelsofenvironmentallysensitive,persistentbiologicallytoxic(PBT),persistentorganicpollutants(POP),or

otherwiserestrictedmaterialsinthisproductarebelowthemaximumconcentrationvalues(alsoreferredtoasthe

thresholdlimits)permittedforsuchsubstances,orareusedinanexemptedapplication,inaccordancewithEUDirec-

tive2002/95/EContherestrictionoftheuseofcertainhazardoussubstancesinelectricalandelectronicequipment

(RoHS), as amended through April 21, 2006.

Vision Advisory Claim

UsersshouldbecautionednottostareatthelightofthisLEDproduct.Thebrightlightcandamagetheeye.

C5SMB-RJS:

C5SMB-BJS:

C5SMA-RJS:







C5SMB-GJS:


