6. Typical Time-To-Trip at 23℃

0.001

0.01

0.1

1

10

100

0.1

1

10

100

Fault current (A)

A

B C D E F

7. Material Specification

Terminal pad material: Pure Tin

Soldering characteristics: Meets EIA specification RS 186-9E, ANSI/J-std-002 Category 3

8. Part Numbering and Marking System

Part Numbering System

Part Marking System

F S M D □ □ □

– 2016 R

F S M D □ □ □

– 2016 – R

F S M D □ □ □

– □ □ – 2016 – R

Voltage Rating

Current Rating

Example

electrical arcing and/or flame.

-PPTC device are intended for occasional overcurrent protection. Application for repeated overcurrent

condition and/or prolonged trip are not anticipated.

甲、

-Avoid contact of PPTC device with chemical solvent. Prolonged contact will damage the device

performance.

Current Rating

□ □ □

F

Fuzetec Logo

A = FSMD030-2016-R

B = FSMD050-2016R

C = FSMD100-2016-R

D = FSMD100-33-2016-R

E = FSMD150-2016-R

F = FSMD200-2016-R

F

Part Identification

□ □ □

F

□ □

Part Identification

Fuzetec Logo
