0150180098 Datasheet(PDF) 1 Page - Molex Electronics Ltd.

No. de pieza 0150180098
Descripción Electrónicos  0.50mm Pitch Premo-Flex FFC Jumper with Ears, Opposite Side Contacts (Type D), 51.00mm Cable Length, Gold (Au) Plating, 10 Circuits
PDF  1 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Fabricante Electrónico  MOLEX [Molex Electronics Ltd.]
Página de inicio  http://www.molex.com
Logo MOLEX - Molex Electronics Ltd.

0150180098 Datasheet(HTML) 1 Page - Molex Electronics Ltd.

  0150180098 Datasheet HTML 1Page - Molex Electronics Ltd.
Zoom Inzoom in Zoom Outzoom out
 1 / 1 page
background image
This document was generated on 02/27/2021
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
0150180098
Status:
Active
Overview:
FFC Cable Jumpers, Premo-Flex Flat-Flexible Cable Jumpers
Description:
0.50mm Pitch Premo-Flex FFC Jumper with Ears, Opposite Side Contacts (Type D),
51.00mm Cable Length, Gold (Au) Plating, 10 Circuits
Documents:
Drawing (PDF)
Datasheet (PDF)
Product Specification 150180001-000 (PDF)
RoHS Certificate of Compliance (PDF)
General
Product Family
Cable
Series
15018
Comments
Opposite Side Contacts, Type D
Crimp Quality Equipment
Yes
Overview
FFC Cable Jumpers, Premo-Flex Flat-Flexible Cable
Jumpers
Product Name
Premo-Flex FFC Jumper
UPC
193264329441
Physical
Cable Length
51.00mm
Circuits (Loaded)
10
Contact Layout Type
D (opposite side)
Material - Plating Mating
Gold
Packaging Type
Bag
Pitch - Mating Interface
0.50mm
Temperature Range - Operating
-40° to +105°C
Wire Size AWG
N/A
Wire/Cable Type
Flat Flex Cable
Electrical
Current - Maximum per Contact
0.5A
Voltage - Maximum
60V AC
Material Info
Reference - Drawing Numbers
Product Specification
150180001-000
Sales Drawing
SD-15018-001-001
Series image - Reference only
EU ELV
Not Relevant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per -
D(2020)9139-DC (19
Jan 2021)
Halogen-Free
Status
Not Low-Halogen
For more information, please visit Contact US
China ROHS
Green Image
ELV
Not Relevant
RoHS Phthalates
Not Contained
Search Parts in this Series
15018 Series
Mates With
Easy-On FFC/FPC Connector 5051101092
This document was generated on 02/27/2021
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
