6 Configuration and Dimensions:

7 Electrical Characteristics:

Inductance

Tolerance

Test Freq.

Irms(A)

Isat(A)

RDC(mΩ)

Marking

(uH)

(±%)

Typ.

Typ.

Max.

MHCI06030-R10M-R8A

0.1

20

100kHz,0.5V

32.5

60

1.7(1.5yp)

R10

MHCI06030-R15M-R8A

0.15

20

100kHz,0.5V

30

40

2.5(1.9yp)

R15

MHCI06030-R22M-R8A

0.22

20

100kHz,0.5V

23

34

3.0(2.5yp)

R22

MHCI06030-R33M-R8A

0.33

20

100kHz,0.5V

21

25

3.5(3.0typ)

R33

MHCI06030-R36M-R8A

0.36

20

100kHz,0.5V

20

24

3.9(3.3typ)

R36

MHCI06030-R47M-R8A

0.47

20

100kHz,0.5V

18

20

4.1(3.5typ)

R47

MHCI06030-R56M-R8A

0.56

20

100kHz,0.5V

16.5

18

4.5(3.9typ)

R56

MHCI06030-R68M-R8A

0.68

20

100kHz,0.5V

16

17

5.3(4.8yp)

R68

MHCI06030-R82M-R8A

0.82

20

100kHz,0.5V

14

16

6.0(5.4typ)

R82

MHCI06030-1R0M-R8A

1

20

100kHz,0.5V

12

15

7.4(6.7typ)

1R0

MHCI06030-1R2M-R8A

1.2

20

100kHz,0.5V

10

14

10(7.8typ)

1R2

MHCI06030-1R5M-R8A

1.5

20

100kHz,0.5V

10

14

12.1(10.6typ)

1R5

MHCI06030-2R2M-R8A

2.2

20

100kHz,0.5V

8

10

15(13.5typ)

2R2

MHCI06030-3R3M-R8A

3.3

20

100kHz,0.5V

6.5

9.5

22(18.0typ)

3R3

MHCI06030-4R7M-R8A

4.7

20

100kHz,0.5V

5.5

6.5

33(28.0typ)

4R7

MHCI06030-5R6M-R8A

5.6

20

100kHz,0.5V

5.5

6

42(39.0typ)

5R6

MHCI06030-6R8M-R8A

6.8

20

100kHz,0.5V

4.5

6

50(43.9typ)

6R8

MHCI06030-8R2M-R8A

8.2

20

100kHz,0.5V

4.5

6

60(54.0typ)

8R2

MHCI06030-100M-R8A

10

20

100kHz,0.5V

4

5.5

68(62.0typ)

100

`

Note:

5.Absolute maximum voltage 30VDC

should be verified in the end application.

Circuit design 125°C under worst case operating conditions. Component placement, PWB trace size

and thickness, airflow and other cooling provisions all affect the part temperature. Part temperature

Part No.

2.Isat for Inductance drop 30% from its value without current.

4.The part temperature (ambient + temp rise) should not exceed 125°C under worst case operating conditions.

1.Operating temperature range -55

℃~125℃(Including self - temperature rise)

3.Irms for a 40

℃ temperature rise from 25℃ ambient.

MHCI0603-3R3M-R8A
