EVK-R4 - User guide
UBX-16029216 - R08
Starting up
Page 5 of 31
C1-Public
SIM card holder
J300
Cellular reset
SW303
Cellular power-on
SW302
GND
9 – 18 V
Power input
J400
Cellular
adapter board
DL400
Main power switch
SW400
DL401
SARA-R410M
Cellular module
DIL B2B connector
J300
DIL B2B connector
J301
GND
Cellular VCC
supply jumper
J404
Cellular USB
(UART)
J501
Cellular RS232
(UART)
J500
DL501
DL403
DL405
SW403
SW401
DL404
SW300
SW304
SW204
DS107
DS105
DS109
DS103
DS500
DS501
GND
GND
Cellular
antenna connector
ANT1 - J103
Cellular native USB
J104
Headset jack
J303
DS100
NEO-M8N GNSS
antenna connector
J208
NEO-M8N
GNSS module
GNSS
adapter board
GNSS USB
J102
DS132
DS118
DS124
DS121
BT200
Figure 1: Overview of the EVK-R410M evaluation kit for SARA-R410M modules
