Data Sheet
ADP2450
Rev. B | Page 21 of 40
CH1 5.00V BW
CH3 2.00V BW CH4 200mA BW
CH2 2.00V BW M1.00ms
CH1
3.20V
1M PTS
T
2.568000ms
3
1
2
4
T
RSTO
VOUT1
VOUT2
IOUT2
Figure 59. Buck Regulator Soft Start with Full Load
(VOUT2 = 3.3 V, Adjustable Version)
CH1 2.00V BW
CH3 10.0V BW CH4 1.00A BW
M1.00ms
CH1
2.92V
1M PTS
T
2.990000ms
3
1
4
SW
VOUT2
IOUT2
T
Figure 60. Buck Regulator OCP Triggered
CH2 200mV
B
W
CH4 200mA BW
M200µs
CH4
236mA
1M PTS
T
598.0000µs
2
4
VOUT2 (AC)
IOUT2
T
Figure 61. Buck Regulator Load Transient (50 mA to 450 mA)
CH1 5.00V BW
CH3 2.00V BW CH4 200mA BW
CH2 5.00V BW M400µs
CH1
4.40V
1M PTS
T
680.0000µs
3
1
2
4
T
RSTO
VOUT1
VOUT2
IOUT2
Figure 62. Buck Regulator Soft Start with Full Load
(VOUT2 = 5 V, Fixed Version)
CH1 2.00V BW
CH3 10.0V BW CH4 1.00A BW
M1.00ms
CH1
2.92V
1M PTS
T
2.590000ms
3
1
4
SW
VOUT2
IOUT2
T
Figure 63. Buck Regulator OCP Recovery
CH2 50.0mV
B
W
CH3 10.0V BW
CH1 10.0V BW
M2.00ms
CH1
21.0V
1M PTS
T
4.716000ms
2
3
1
VOUT2 (AC)
VIN
SW
T
Figure 64. Buck Regulator Line Transient, VIN from 8 V to 24 V, Full Load
