RGP300 datasheet(1/2 Pages) DEC

No. de pieza	RGP300

Descripción Electrónicos	3 AMP HIGH RELIABILITY FAST RECOVERY DIODES

PDF	2 Pages

Scroll/Zoom	100%

Fabricante Electrónico	DEC [DIOTEC Electronics Corporation]

Página de inicio	http://www.diotec-usa.com

Logo

1 / 2 page

FEATURES

Data Sheet No. FSPD-300-1B

MECHANICAL SPECIFICATION

3 AMP HIGH RELIABILITY FAST RECOVERY DIODES

Tel.: (310) 767-1052

Fax: (310) 767-7958

DIOTEC ELECTRONICS CORP.

Gardena, CA 90248

U.S.A

18020 Hobart Blvd., Unit B

H33

MECHANICAL DATA

ACTUAL SIZE OF

DO-27 PACKAGE

Color Band

Denotes

Cathode

LD (Dia)

BD (Dia)

LL

BL

LL

SERIES RGP300 - RGP310

Sym

In

mm

Minimum

Maximum

BL

BD

LL

LD

1.00

0.048

In

mm

0.365

0.205

0.052

9.28

5.2

1.3

25.4

1.2

MAXIMUM RATINGS & ELECTRICAL CHARACTERISTICS

PARAMETER (TEST CONDITIONS)

SYMBOL

RATINGS

UNITS

DO - 27

EXTREMELY LOW LEAKAGE AT HIGH TEMPERATURES

LOW FORWARD VOLTAGE DROP

3A at T = 55 C WITH NO THERMAL RUNAWAY

VOID FREE VACUUM DIE SOLDERING FOR MAXIMUM

MECHANICAL STRENGTH AND HEAT DISSIPATION

(Solder Voids: Typical < 2%, Max. < 10% of Die Area)
