SRL60 LOCK SWITCH

ELECTRICAL & MECHANICAL SPECIFICATION

Switch Rating:

1A @24V ac/dc.

Life:

>10,000 Cycles

Proof Voltage:

1500 Vac (Initial)

Lock Type:

5 Disc

Insulation Resistance:

>999MΩ @ 500V dc (Initial)

Lock Housing:

Zinc Alloy Bright Cr Plated

Contact Resistance:

<20mΩ (Initial)

Wafer Material:

Polyamide 6.6 G>F. V0 Rated

Contact Material:

Brass CZ108, Ag Plated

Housing Material:

Polycarbonate

Operating Temperature:

-30°C to +85°C

FEATURES

LOCK SWITCH

SRL60

Contacts: Non shorting BBM

Gold flashed or gold plate contacts available

Solder or PCB terminals

2 keys per switch - Up to 200 differ

key combinations available

Keys are double entry (can be

inserted into lock either way up)

Key removable at 60° positions

Single wafer switch

One - four poles

Two stage assembly: Lock through front,

module snaps on from rear

Max panel thickness 4.5mm

Made In UK
