STEGO - PRODUCT CATALOGUE

These small heaters are designed to prevent condensation and to ensure a minimum operating temperature in

small enclosures. The heaters are designed for permanent operation.

> Wide voltage range

> Dynamic heating up

> Energy saving

> Compact

Example of connection

Thermostat

KTO 011 (NC)

Heater RC 016

TECHNICAL DATA

Operating voltage

AC/DC 120 – 240 V¹ (min. 110 V, max. 265 V)

Heating element

PTC resistor – temperature limiting

Heater body

aluminium, anodised

Mounting

screw fixing

Fitting position

variable

Operating/Storage temperature

-45 to +70 °C (-49 to +158 °F)

Operating/Storage humidity

max. 90 % RH (non-condensing)

Protection type/Protection class

IP54 / II (double insulated)

Approvals

VDE, UL File No. E150057 (according to UL 508A, NITW File on

request), EAC

Note

other voltages on request

¹ Operating with voltages below AC/DC 140 V reduces heating performance by approx. 10 %.

Art. No.

Heating capacity²

Inrush current max.

Recommended pre-fuse T (time-delay)

Surface temperature (approx.)

Connection

Weight (approx.)

01602.0-00

8 W

2.0 A

2.0 A

+150 °C

2 x AWG 18 stranded wire

20 g

01609.0-00

10 W

2.5 A

4.0 A

+155 °C

2 x AWG 22 cable (silicone)

30 g

01610.0-00

13 W

3.0 A

4.0 A

+170 °C

2 x AWG 22 cable (silicone)

40 g

² at +20 °C (+68 °F) ambient temperature

SMALL SEMICONDUCTOR HEATER

RC 016 | 8 W, 10 W, 13 W

Art. No. 01602.0-00

Art. No. 01609.0-00

Art. No. 01610.0-00

HEATING

15

TECHNICAL DATASHEET
