AD8538/AD8539

Rev. A | Page 7 of 24

ABSOLUTE MAXIMUM RATINGS

T = 25°C, unless otherwise noted.

THERMAL RESISTANCE

Table 5.

θJA

Parameter

Rating

is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Supply Voltage

+6 V

Table 6. Thermal Characteristics

Input Voltage

V − 0.3 V to V

+ 0.3 V

Package Type

Unit

Differential Input Voltage

±6 V

5-Lead TSOT-23 (UJ-5)

207

°C/W

Output Short-Circuit Duration to GND

Observe derating curve

Storage Temperature Range

–65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

Operating Temperature Range

–40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

Absolute maximum ratings apply at 25°C, unless otherwise noted.

8-Lead SOIC_N (R-8)

125

°C/W

8-Lead MSOP (RM-8)

145

°C/W

ESD CAUTION
