AD8123

Rev. 0 | Page 4 of 16

Parameter

Conditions

Min

Typ

Max

Unit

POWER SUPPLY

Operating Voltage Range

±4.5

±5.5

Positive Quiescent Supply Current

132

Negative Quiescent Supply Current

126

Supply Current Drift, ICC/IEE

μA/°C

Positive Power Supply Rejection Ratio

DC, referred to output

−51

Negative Power Supply Rejection Ratio

DC, referred to output

−63

Power Down, VIH (Minimum)

Minimum Logic 1 voltage

1.1

Power Down, VIL (Maximum)

Maximum Logic 0 voltage

0.8

Positive Supply Current, Powered Down

VPEAK = VGAIN = VPOLE = 0 V

1.1

μA

Negative Supply Current, Powered Down

VPEAK = VGAIN = VPOLE = 0 V

0.7

μA

COMPARATORS

Output Voltage Levels

VOH/VOL

3.33/0.043

Hysteresis

VHYST

Propagation Delay

tPD, LH/tPD, HL

17.5/10.0

Rise/Fall Times

tRISE/tFALL

9.3/9.3

Output Resistance

0.03

OPERATING TEMPERATURE RANGE

−40

+85

°C
