HDSP-R881 Datasheet(PDF) 4 Page - Agilent(Hewlett-Packard)

No. de pieza HDSP-R881
Descripción Electrónicos  8 x 8 Rich Color General Purpose Dot Matrix Displays 47.8 mm (1.88 inch) Package
PDF  11 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Fabricante Electrónico  HP [Agilent(Hewlett-Packard)]
Página de inicio  http://www.home.agilent.com
Logo HP - Agilent(Hewlett-Packard)

HDSP-R881 Datasheet(HTML) 4 Page - Agilent(Hewlett-Packard)

  HDSP-R881 Datasheet HTML 1Page - Agilent(Hewlett-Packard) HDSP-R881 Datasheet HTML 2Page - Agilent(Hewlett-Packard) HDSP-R881 Datasheet HTML 3Page - Agilent(Hewlett-Packard) HDSP-R881 Datasheet HTML 4Page - Agilent(Hewlett-Packard) HDSP-R881 Datasheet HTML 5Page - Agilent(Hewlett-Packard) HDSP-R881 Datasheet HTML 6Page - Agilent(Hewlett-Packard) HDSP-R881 Datasheet HTML 7Page - Agilent(Hewlett-Packard) HDSP-R881 Datasheet HTML 8Page - Agilent(Hewlett-Packard) HDSP-R881 Datasheet HTML 9Page - Agilent(Hewlett-Packard) Next Button
Zoom Inzoom in Zoom Outzoom out
 4 / 11 page
background image
4
Internal Circuit Diagram
5
7
6
1
COL
1
1
ROW
PIN
2
2
3
3
4
4
20
5
19
6
18
7
17
8
8
10
9
2
11
13
12
3
14
16
15
4
21
23
22
5
24
26
25
6
27
29
28
7
30
32
31
8
RED
BLUE
GREEN
COMMON ROW ANODE
PIN
FUNCTION
PIN
1
ROW 1 ANODE
2
ROW 2 ANODE
3
ROW 3 ANODE
4
ROW 4 ANODE
5
COLUMN 1 RED CATHODE
6
COLUMN 1 GREEN CATHODE
7
COLUMN 1 BLUE CATHODE
8
COLUMN 2 RED CATHODE
9
COLUMN 2 GREEN CATHODE
10
COLUMN 2 BLUE CATHODE
11
COLUMN 3 RED CATHODE
12
COLUMN 3 GREEN CATHODE
17
18
19
20
21
22
23
24
25
26
27
28
FUNCTION
13
COLUMN 3 BLUE CATHODE
29
14
COLUMN 4 RED CATHODE
30
15
COLUMN 4 GREEN CATHODE
31
16
COLUMN 4 BLUE CATHODE
32
ROW 8 ANODE
ROW 7 ANODE
ROW 6 ANODE
ROW 5 ANODE
COLUMN 5 RED CATHODE
COLUMN 5 GREEN CATHODE
COLUMN 5 BLUE CATHODE
COLUMN 6 RED CATHODE
COLUMN 6 GREEN CATHODE
COLUMN 6 BLUE CATHODE
COLUMN 7 RED CATHODE
COLUMN 7 GREEN CATHODE
COLUMN 7 BLUE CATHODE
COLUMN 8 RED CATHODE
COLUMN 8 GREEN CATHODE
COLUMN 8 BLUE CATHODE
