STA538
Connection diagrams and pin descriptions
9/59
2.2
VFQFPN52 package
2.2.1
Connection diagram
Figure 3 shows the connection diagram for the VFQFPN52 package.
Figure 3.
Package: VFQFPN52
40
52
1
13
39
27
26
14
