INPUT AND OUTPUT PORT MATCHING

analog.com

Rev. E | 39 of 53

The ADL6337 has four variants for four operating frequency rang-

es. Each variant has different input port matching schemes. The

ADL6337-A requires external matching components for a 50 Ω in-

put impedance to achieve the return loss specification, and external

matching components are required for 100 Ω source matching. See

Figure 122. The ADL6337-B, the ADL6337-C, and ADL6337-D do

not require any external components to match the 50 Ω input impe-

dance. However, the external matching components must match

the single-ended 50 Ω load impedance only for the ADL6337-C and

ADL6337-D. Additionally, the external matching components must

match the 100 Ω input source impedance. See Figure 123, Figure

124, and Figure 125. Note that the matching components can be

changed due to the board structures and materials.

Figure 122. Input Matching Components for the ADL6337-A

Figure 123. Input Matching Components for the ADL6337-B

Figure 124. Input and Output Components for the ADL6337-C

Figure 125. Input and Output Components for the ADL6337-D
