isc N-Channel MOSFET Transistor

STD4N52K3

www.iscsemi.com

2

ELECTRICAL CHARACTERISTICS（TC=25℃ unless otherwise specified）

SYMBOL

PARAMETER

CONDITIONS

MIN

TYP.

MAX

UNIT

V(BR)DSS

Drain-Source Breakdown Voltage

VGS= 0V; ID= 1.0mA

525

--

--

V

IDSS

Zero Gate Voltage Drain Current

VDS=525V; VGS= 0V

--

--

1

μ

A

IGSS

Gate-Body Leakage Current

VGS= ±20V;VDS= 0V

--

--

±

10

μ

A

VGS(th)

Gate Threshold Voltage

VDS= VGS; ID= 50μA

3.0

--

4.5

V

RDS(on)

Drain-Source On-Resistance

VGS= 10V; ID= 1.25A

--

--

2.6

Ω

VSD

Forward On-Voltage

IS= 2.5A; VGS= 0V

--

--

1.6

V
