PACKAGE MATERIALS INFORMATION
www.ti.com
23-May-2025
TRAY
L - Outer tray length without tabs
KO -
Outer
tray
height
W -
Outer
tray
width
P1 - Tray unit pocket pitch
CW - Measurement for tray edge (Y direction) to corner pocket center
CL - Measurement for tray edge (X direction) to corner pocket center
Text
Chamfer on Tray corner indicates Pin 1 orientation of packed units.
*All dimensions are nominal
Device
Package
Name
Package
Type
Pins
SPQ
Unit array
matrix
Max
temperature
(°C)
L (mm)
W
(mm)
K0
(µm)
P1
(mm)
CL
(mm)
CW
(mm)
CC2550-RTY1
RST
VQFNP
16
490
14x35
150
322.6
135.9
7620
8.8
7.9
8.15
CC2550RST
RST
VQFNP
16
490
14x35
150
322.6
135.9
7620
8.8
7.9
8.15
CC2550RST.B
RST
VQFNP
16
490
14x35
150
322.6
135.9
7620
8.8
7.9
8.15
Pack Materials-Page 3
