Product Information • SCL-RHYTHM • M.2 NVMe & Quad M12 Gigabit Ethernet

Features

Feature Summary

General

<

Mixed function mezzanine side card for EKF CompactPCI® Serial CPU boards

<

Based on new mezzanine connectors HSE1/HSE2 (8 x PCIe® Gen3)

<

Suitable e.g. for use with CPU cards SC4-CONCERTO or SC5-FESTIVAL

<

Provides Gigabit Ethernet front panel I/O (4 x M12-X)

<

Provides mass storage capability (M.2 NVMe)

<

8HP assembly together with CPU card

<

Proprietary PCB dimensions for optimized CPU card processor heat sink

Front Panel I/O

<

4 x M12 X-coded front panel GbE receptacles, rail approved, Cat6A, IEC 61076-2-109

<

1000BASE-T, 100BASE-TX, 10BASE-T compliant data transfer rate front ports

<

Future proof investment into cabling infrastructure - up to 10Gbps with M12 Cat6A

<

M12 X-coded to RJ45 connector Cat6A cable assemblies available from several suppliers

Networking

<

Four individual networking interface controllers (NIC), based on PCI Express®

<

1000BASE-T, 100BASE-TX, 10BASE-T connections

<

Intel® I210-IT -40°C to +85°C operating temperature GbE controllers w. integrated PHY

<

IPv4/IPv6 checksum offload, 9.5KB Jumbo Frame support, EEE Energy Efficient Ethernet

<

IEEE 802.1Qav Audio-Video-Bridging (AVB) enhancements for time-sensitive streams

(TSN)

<

IEEE 1588 and 802.1AS packets time stamping for high-precision time synchronization

<

All GbE ports wired via M12 X-coded front panel connectors

On-Board Mass Storage

<

M.2 (formerly known as NGFF) socket for an NVMe type SSD module up to 2280 size

<

PCI Express® Gen3 x4 interface (M-key socket)

<

Socket height 4.2H (double sided module allowed)

<

Capacity up to 2TB as of current

<

Suitable for operating system installation (boot device)
