MPS-GR SERIES DIMENSIONS
MPS50GR
50
35
4
27
54
127
9.5
4X
3.4 THRU ALL
6.5 TO DEPTH SHOWN
0.8
31.5
A
STAGE CABLE EXIT
3M LENGTH
25
12.5
5
20.5
TYP
41.5
0.8
4X M3X0.5 HELICOIL 4.5 MAX
THREAD NO DEEPER
DAMAGE TO STAGE CAN RESULT
50
REF
35 REF
20 CLEAR
APERTURE
4X M4X0.7 8
58
26
23 SQ
20 H6 5.75
4X M3X0.5 4
DETAIL A
DIMENSIONS: MILLIMETERS
