AD8605/AD8606/AD8608

Rev. H | Page 8 of 24

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage

6 V

Input Voltage

GND to VS

Differential Input Voltage

6 V

Output Short-Circuit Duration to GND

Observe Derating Curves

Storage Temperature Range

All Packages

−65°C to +150°C

Operating Temperature Range

All Packages

−40°C to +125°C

Junction Temperature Range

All Packages

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

Table 4.

Package Type

θJA1

θJC

Unit

5-Ball WLCSP (CB)

170

°C/W

5-Lead SOT-23 (RJ)

240

°C/W

8-Ball WLCSP (CB)

115

°C/W

8-Lead MSOP (RM)

206

°C/W

8-Lead SOIC_N (R)

157

°C/W

14-Lead SOIC_N (R)

105

°C/W

14-Lead TSSOP (RU)

148

°C/W

1 θJA is specified for the worst-case conditions, that is, a device soldered in a

circuit board for surface-mount packages.

ESD CAUTION

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.
