AD8502/AD8504

Rev. 0 | Page 6 of 16

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage

6 V

Input Voltage

Differential Input Voltage

±6 V

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

Absolute maximum ratings apply at 25°C, unless otherwise noted.

THERMAL RESISTANCE

soldered in a circuit board for surface-mount packages.

Table 4. Thermal Characteristics

Package Type

Unit

8-Lead SOT-23 (RJ-8)

376

126

°C/W

14-Lead TSSOP (RU-14)

180

35

°C/W

ESD CAUTION
