REV. D
AD8601/AD8602/AD8604
–11–
TIME – 1s/DIV
VS = 5V
TA = 25 C
TPC 40. 0.1 Hz to 10 Hz Input Voltage Noise
50.0mV/DIV
200ns/DIV
VS = 5V
RL = 10k
CL = 200pF
TA = 25 C
TPC 41. Small Signal Transient Response
50.0mV/DIV
200ns/DIV
VS = 2.7V
RL = 10k
CL = 200pF
TA = 25 C
TPC 42. Small Signal Transient Response
VS = 5V
TA = 25 C
FREQUENCY – kHz
0
0
0.5
1.0
1.5
2.0
2.5
26
52
78
104
130
156
182
208
TPC 37. Voltage Noise Density vs. Frequency
VS = 5V
TA = 25 C
FREQUENCY – kHz
0
05
10
15
20
25
8
16
24
32
40
48
56
64
TPC 38. Voltage Noise Density vs. Frequency
TIME – 1s/DIV
VS = 2.7V
TA = 25 C
TPC 39. 0.1 Hz to 10 Hz Input Voltage Noise
