 4 / 28 page
background image
ADL5382
Rev. 0 | Page 4 of 28
Parameter
Condition
Min
Typ
Max
Unit
DYNAMIC PERFORMANCE at RF = 2700 MHz
RFIP, RFIN
Conversion Gain
3.3
dB
Input P1dB
14.5
dBm
Second-Order Input Intercept (IIP2)
−5 dBm each input tone
52
dBm
Third-Order Input Intercept (IIP3)
−5 dBm each input tone
28.3
dBm
LO to RF
RFIN, RFIP terminated in 50 Ω, 1xLO appearing at RF port
−70
dBm
RF to LO
LOIN, LOIP terminated in 50 Ω
−55
dBc
IQ Magnitude Imbalance
0.16
dB
IQ Phase Imbalance
0.1
Degrees
LO to IQ
RFIN, RFIP terminated in 50 Ω, 1xLO appearing at BB port
−42
dBm
Noise Figure
17.6
dB
