8200 Series Dissipative Vinyl Three-Layer Mats and Rolls are soft table

mats with a three-layer construction that meet ANSI/ESD S20.20 tested

per worksurface standard ANSI/ESD STM4.1-2017. The top color layer

is durable static dissipative vinyl, which has sufficiently low resistance to

discharge static-laden conductors, yet will help prevent the shorting of pins

on the backs of printed circuit boards laid on the mat. The middle layer is a

highly-conductive scrim that provides the main discharge path to ground,

and the bottom layer is static-dissipative foam, providing a durable nonskid

cushion. Compatible with Constant Monitors.

DRAWING

NUMBER

8200 Series

DATE

October

2022

© 2022 DESCO INDUSTRIES INC

Employee Owned

8200 SERIES DISSIPATIVE VINYL THREE-LAYER MATS AND ROLLS

926 JR Industrial Drive, Sanford, NC 27332

WEB SITE: StaticControl.com

PHONE (919) 718-0000 | WEST: (909) 627-9634

Properties

Typical Value

Material

Top Layer - Static Dissipative Vinyl

Middle Layer - Highly Conductive Scrim

Bottom Layer - Static Dissipative Foam

Color*

Blue, Brown, Gray, Dark Blue

Thickness

0.140" (3.5 mm)

Hardness (top)

78 Shore A

Resistance

Surface to Ground (Rtg)

Surface to Surface (Rtt)

1 x 106 to < 1 x 109 ohms

1 x 106 to < 1 x 109 ohms

Tolerance

Width +/- 0.250"

Length +/- 0.250"

Table Mat Kit Item Numbers

Size

Blue Brown

Gray

Dark Blue

24" x 48" (0.6 m x 1.2 m)

8214

8211

8213

8215

30" x 60" (0.8 m x 1.5 m)

8216

Table Mat Kit Includes:

1 Table Mat, size as specified

1 3048 Wrist Strap Grounding System

2 3050 Single Snap Fastener (Snaps installed on long side of mat)

Floor Mat Kit Includes:

1 Floor Mat, size as specified

1 3040 15' (4.6 m) Ground Cord

2 3050 Single Snap Fastener (Snaps installed on long side of mat)

Table Roll Item Numbers without Hardware

Size

Blue Brown Gray

Dark Blue

2' x 50' (0.6 m x15.2 m)

8234

8231

8233

8245

2.5' x 50' (0.8 m x 15.2 m)

8244

8241

8243

8246

3' x 50' (0.8 m x 15.2 m)

8274

8271

8273

8247

4' x 50' (1.2 m x 15.2 m)

82A4

82A1

82A3

Table Roll Item Numbers with Hardware

Size

Blue Brown

Gray

2' x 24' (0.6 m x 7.3 m)

8264

8261

8263

4' x 24' (1.2 m x 7.3m)

8254

8251

8253

Table Roll Includes:

2 3040 15' (4.6 m) Ground Cords

2 3050 Single Snap Fastener (not installed)

Specifications and procedures subject to change without notice.

Made in the

United States of America

*Color and texture may vary between lots and mills

Floor Mat Kit Item Numbers

Size

Blue

Gray

48" x 72" (1.2 m x 1.8 m)

8204

8203

RoHS, REACH and Conflict Minerals, Statement

See the Desco Industries RoHS, REACH, and Conflict Minerals Statement:

DescoIndustries.com/RoHS3.aspx

See the SCS Limited Warranty

Staticcontrol.Descoindustries.com/Limited-Warranty.aspx
