900 MHz 5 dBi RP-SMA Plug RIGID Connector High

Performance "Rubber Duck" Wireless LAN Antenna

Applications and Features

Applications:

•

900MHz ISM Band

•

Cellular Band Applications

•

900MHz Digital Spread Spectrum Radios

•

900MHz Telemetry Products

•

GSM

•

RFID

•

Wireless Video Transmitters and Receivers

•

Multipoint and Mobile Applications

Features:

•

Better performance than most stock AP antennas

•

Flexible "Rubber Duck" antenna

•

RIGID connector seals antenna connections

•

Reverse Polarity SMA-Plug (RP-SMA) Connector

•

RoHS Compliant

HG905RDR-RSP

Description

This high performance 900MHz Omni-directional "rubber-duck" antenna provides broad coverage and 5 dBi gain. It is a coaxial

sleeve design with an Omni-directional pattern. It is ideally suited for 900MHz ISM band applications as well as cellular

applications.

Measuring almost 17 inches long, this flexible antenna features a RIGID connection to the Reverse Polarity SMA-Plug (RP-SMA)

connector, permitting upright solid installations to the radio or Coax. It is suitable as a replacement RF antenna for many

900MHz radios that are equipped with RP-SMA connectors such as wireless video transmitters and receivers, 900MHz digital

spread spectrum radios and more.

Specifications

Electrical Specifications

Frequency

900-930 MHz

Gain

5 dBi

Horizontal Beam Width

360°

Impedance

50 Ohm

Max. Power

50W

VSWR

≤ 2.5

Lightning Protection

DC Ground
