E3S-A

Diffuse-reflective Sensors (Vertical)

Pre-wired Sensors

Sensors with Connectors

29.2

1.2 10.7

10.5

3.1

47.2

5.5 5.4

7.2

16.9

28.9

4.8

Stainless

steel

(SUS304)

*The Mounting Bracket can be attached to side A.

Optical axis

Optical

axis

Two, M3

× 12 screws

With Mounting Bracket Attached

E3S-AD61/62/63/71/72/73

-AD81/82/83/91/92/93

5.5

3.6

1.3

10.5

(4)

8.8 dia.

12.4

Emitter

Receiver

*1. E3S-AD61, E3S-AD62, E3S-AD63, E3S-AD81, E3S-AD82, and E3S-AD83 have

three conductors.

*2. Timer adjuster: Not available on E3S-AD61, E3S-AD62, E3S-AD63, E3S-AD81,

E3S-AD82 and E3S-AD83.

Turbo switch: Available on E3S-AD71 and E3S-AD91 only.

Lens (7

× 14)

Optical axis

Two, M3

× 12 screws

Stability indicator

(green)

Light indicator (red)

Operation mode

selector

Two, M3 holes

4-dia. vinyl-insulated

round cable

with 4 conductors

(Conductor cross

section: 0.2 mm2,

Insulator diameter:

1.1 mm),

Standard length:

2 m *1

Sensitivity

adjuster

(white)

Timer adjuster/

Turbo switch (black) *2

Turn to adjust the timer:

push to switch turbo function

Mounting Holes

E3S-AD66/67/68/86/87/88

29.2

1.2 10.7

10.5

3.1

41.7

5.4

7.2

19.4

31.4

4.8

Use these

two holes

for

mounting.

Stainless steel

(SUS304)

*The Mounting Bracket can be attached to side A.

Optical axis

Optical

axis

Two, M3

× 12 screws

E39-L60 Close Mounting Plate (provided)

(Attach the mounting plate or the

plug cannot be connected.)

With Mounting Bracket Attached

3.6

1.3

10.5

(10)

Receiver

Lens (7

× 14)

Optical axis

Two, M3

× 12 screws

Stability indicator

(green)

Light indicator (red)

Operation

mode

selector switch

Two, M3 holes

Sensitivity

adjuster

(white)

Emitter

Connector

M12

Mounting Holes
