AV Input

USB-C

DisplayPort - 1.4

AV Output

DisplayPort

USB-C

Audio

Yes

Chipset ID

Chrontel - CH7213C-BF

Texas Instruments - TUSB544

VIA Labs - VL170

Performance

Video Revision

DisplayPort 1.4

Maximum Digital

Resolutions

DisplayPort: 7680x4320 (8K) / 60Hz

USB-C: 7680x4320 (8K) / 60Hz

Wide Screen Supported

Yes

Bandwidth

HBR3

Audio Specifications

DisplayPort - 7.1 Channel Audio

USB-C - 7.1 Channel Audio

Connector(s)

Connector A

1 - USB-C (24 pin) DisplayPort Alt Mode

1 - Thunderbolt 3 USB-C (24-pin) (40Gbps)

Connector B

1 - DisplayPort (20 pin)

Special Notes /

Requirements

System and Cable

Requirements

Your USB-C device must support DisplayPort Alt Mode to work

with this cable

To achieve 8K resolutions, your source and your destination

must support DisplayPort 1.4

This cable is not compatible with the Surface Dock 2

Environmental

Operating Temperature

0C to 45C (32F to 113F)
