AV Output

DisplayPort - 1.4

Chipset ID

STM32F072CBY6TR

Performance

Video Revision

DisplayPort 1.4

Supported Resolutions

DisplayPort: 7680x4320 (8K) / 60Hz

Wide Screen Supported

Yes

Bandwidth

HBR3

Audio Specifications

DisplayPort - 7.1 Channel Audio

Connector(s)

Connector A

1 - USB-C (24 pin) DisplayPort Alt Mode

Connector B

1 - DisplayPort (20 pin)

Special Notes /

Requirements

System and Cable

Requirements

Your USB-C port must support DisplayPort over USB-C (DP Alt

mode) in order to work with this adapter.

To achieve 8K resolutions, your source and your destination

must support DisplayPort 1.4.

Environmental

Operating Temperature

5C to 35C (41F to 95F)

Storage Temperature

-20C to 60C (-4F to 140F)

Humidity

80%-90%RH

Physical

Characteristics

Color

Black

Product Length

6.0 ft [1.8 m]

Product Width

7.9 in [20.0 cm]

Product Height

0.4 in [1.1 cm]

Weight of Product

2.0 oz [57.0 g]

Packaging
