ABSOLUTE MAXIMUM RATINGS

TA = 25°C, unless otherwise noted.

Table 3.

Parameters

Rating

VDD to GND

−0.3 V to +6 V

Analog, Digital Inputs1

−0.3 V to VDD + 0.3 V or 30 mA,

whichever occurs first

Continuous Current, S or D

100 mA

Peak Current, S or D

300 mA (pulsed at 1 ms,

10% duty cycle max)

Operating Temperature Range

Industrial (B Version)

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Junction Temperature

150°C

Thermal Impedance, θJA

16-Lead QSSOP

105.44°C/W2

16-Lead LFCSP (3 mm × 3 mm)

48.7°C/W2

Lead Temperature Soldering

Vapor Phase (60 sec)

215°C

Infrared (15 sec)

220°C

Reflow Soldering (Pb-free)

Peak Temperature

260°C (+0°C/–5°C)

Time at Peak Temperature

10 sec to 40 sec

1 Overvoltages at IN, S, or D are clamped by internal diodes. Current should be

limited to the maximum ratings given.

2 Measured with the device soldered on a four-layer board.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.
