AD8260

Rev. 0 | Page 6 of 32

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Voltage

Supply Voltage (VPOS, VNEG)

±6 V

Input Voltage (INxx, PRAI,

FDBK, VMDI, VOCM)

VPOS, VNEG

Logic Voltages

VPOS, ground

Temperature

Operating Temperature Range

–40°C to +105°C

Storage Temperature Range

–65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

Thermal Data1

Maximum Junction Temperature

125°C

θJA

47.3°C/W

θJC

6.9°C/W

θJB

28.6°C/W

ΨJT

0.6°C/W

ΨJB

27.4°C/W

1 Thermal data at zero airflow with exposed pad soldered to four-layer JEDEC

board with vias per JESD51-5.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.
