STF92 Datasheet(PDF) 2 Page - STMicroelectronics

No. de pieza STF92
Descripción Electrónicos  SMALL SIGNAL PNP TRANSISTOR
PDF  4 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Fabricante Electrónico  STMICROELECTRONICS [STMicroelectronics]
Página de inicio  http://www.st.com
Logo STMICROELECTRONICS - STMicroelectronics

STF92 Datasheet(HTML) 2 Page - STMicroelectronics

  STF92 Datasheet HTML 1Page - STMicroelectronics STF92 Datasheet HTML 2Page - STMicroelectronics STF92 Datasheet HTML 3Page - STMicroelectronics STF92 Datasheet HTML 4Page - STMicroelectronics
Zoom Inzoom in Zoom Outzoom out
 2 / 4 page
background image
THERMAL DATA
Rthj-amb
• Thermal Resistance Junction-Ambient
Max
96.1
oC/W
• Device mounted on a PCB area of 1 cm2
ELECTRICAL CHARACTERISTICS (Tcase = 25
oC unless otherwise specified)
Symbol
Parameter
Test Conditions
Min.
Typ.
Max.
Unit
ICBO
Collector Cut-off
Current (IE = 0)
VCB = -200 V
VCB = -200 V
TC = 150
oC
VCB = -300 V
-10
-10
-100
nA
µA
µA
IEBO
Emitter Cut-off Current
(IC = 0)
VEB = -5 V
-50
nA
V(BR)CBO
Collector-Base
Breakdown Voltage
(IE = 0)
IC = -100
µA
-300
V
V(BR)CEO
∗ Collector-Emitter
Breakdown Voltage
(IB = 0)
IC = -10 mA
-300
V
V(BR)EBO
Emitter-Base
Breakdown Voltage
(IC = 0)
IE = -100
µA
-5
V
VCE(sat)
∗ Collector-Emitter
Saturation Voltage
IC = -30 mA
IB = -5 mA
-0.6
V
VBE(sat)
∗ Base-Emitter
Saturation Voltage
IC = -30 mA
IB = -5 mA
-1.2
V
hFE
∗
DC Current Gain
IC = -30 mA
VCE = -10 V
75
fT
Transition Frequency
IC = -15mA VCE = -10V f = 20 MHz
60
MHz
CCBO
Collector-Base
Capacitance
IE = 0
VCB = -10 V f = 1 MHz
6
pF
CEBO
Emitter-Base
Capacitance
IC = 0
VEB = -2 V f = 1 MHz
22
pF
∗ Pulsed: Pulse duration = 300 µs, duty cycle ≤ 1.5 %
STF92
