SSM2335CBZ-R2 Datasheet(PDF) 10 Page - Analog Devices

No. de pieza SSM2335CBZ-R2
Descripción Electrónicos  Filterless, High Efficiency, Mono 3 W Class-D Audio Amplifier
PDF  16 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Fabricante Electrónico  AD [Analog Devices]
Página de inicio  http://www.analog.com
Logo AD - Analog Devices

SSM2335CBZ-R2 Datasheet(HTML) 10 Page - Analog Devices

Back Button SSM2335CBZ-R2 Datasheet HTML 6Page - Analog Devices SSM2335CBZ-R2 Datasheet HTML 7Page - Analog Devices SSM2335CBZ-R2 Datasheet HTML 8Page - Analog Devices SSM2335CBZ-R2 Datasheet HTML 9Page - Analog Devices SSM2335CBZ-R2 Datasheet HTML 10Page - Analog Devices SSM2335CBZ-R2 Datasheet HTML 11Page - Analog Devices SSM2335CBZ-R2 Datasheet HTML 12Page - Analog Devices SSM2335CBZ-R2 Datasheet HTML 13Page - Analog Devices SSM2335CBZ-R2 Datasheet HTML 14Page - Analog Devices Next Button
Zoom Inzoom in Zoom Outzoom out
 10 / 16 page
background image
SSM2335
Rev. 0 | Page 10 of 1
6
–100
–90
–80
–70
–60
–50
–40
–30
–20
–10
0
10
100
1k
10k
100k
FREQUENCY (Hz)
0
–1
1
2
3
4
6
5
–2
TIME (ms)
–2
2
0
4
6
8
10
12
14
16
18
OUTPUT
SD INPUT
Figure 27. Power Supply Rejection Ratio (PSRR) vs. Frequency
Figure 29. Turn-On Response
–100
–90
10
100
1k
10k
100k
FREQUENCY (Hz)
–80
–70
–60
–50
–40
–30
–20
–10
0
0
–1
1
2
3
4
7
6
5
OUTPUT
SD INPUT
–2
TIME (µs)
–90
–50
–70
–30
–10
1030507090
Figure 28. Common-Mode Rejection Ratio (CMRR) vs. Frequency
Figure 30. Turn-Off Response
