background image
Inchange Semiconductor
Product Specification
Silicon NPN Power Transistors
2SD235
DESCRIPTION
·With TO-220 package
·Complement to type 2SB435
APPLICATIONS
·For low frequency power amplifier
and switching applications
PINNING
PIN
DESCRIPTION
1
Base
2
Collector;connected to
mounting base
3
Emitter
Absolute maximum ratings(Ta=25℃)
SYMBOL
PARAMETER
CONDITIONS
VALUE
UNIT
VCBO
Collector-base voltage
Open emitter
50
V
VCEO
Collector-emitter voltage
Open base
40
V
VEBO
Emitter-base voltage
Open collector
6
V
IC
Collector current
3
A
1.5
PC
Collector power dissipation
TC=25℃
25
W
Tj
Junction temperature
150
℃
Tstg
Storage temperature
-55~150
℃
