Mounting Considerations
Mount these devices with brown mark facing up. Units: mm
Line width should be designed to provide 50
Ω impedance matching characteristics.
a) Without Matching Circuits
b) With Matching Circuits
0 Ohm
4.5 mm
9.6 mm
0. 6mm
1.3 mm
0.8 mm
1.5 mm
12.6 mm
5.5 mm
0.7 mm
1 mm
3.9 pF
3.9 pF
10 nH
Via
0.7 mm
0.7 mm
CTMCA1105-R92
ctparts.com
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322 Inside US
949-453-1811 Outside US
Copyright © 2005 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
CENTRAL
Multi-layer Chip Antennas
02.08.05
