ADL5604

Rev. 0 | Page 7 of 24

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage, VSUP

6.5 V

Input Power (50 Ω Impedance)

+25 dBm

Internal Power Dissipation (Paddle Soldered)

3.9 W

θJA (Junction to Air)

32.1°C/W

θJC (Junction to Paddle)

6°C/W

Maximum Junction Temperature

150°C

Lead Temperature (Soldering, 60 sec)

240°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

ESD CAUTION

ADL5604ACPZ-R7 Datasheet(PDF) 7 Page - Analog Devices
