ADA4091-2/ADA4091-4

Rev. E | Page 6 of 20

ABSOLUTE MAXIMUM RATINGS

Table 5.

Parameter

Rating

Supply Voltage

36 V

Input Voltage

Refer to the Input

Overvoltage Protection

section

Differential Input Voltage1

±VSY

Input Current

±5 mA

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

Input current should be limited to ±5 mA.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

θJA is specified for the device soldered on a 4-layer JEDEC standard

PCB with zero airflow. The exposed pad is soldered to the

application board.

Table 6. Thermal Resistance

Package Type

θJA

θJC

Unit

8-Lead SOIC (R-8)

155

°C/W

14-Lead TSSOP (RU-14)

112

°C/W

8-Lead LFCSP (CP-8-9)

°C/W

16-Lead LFCSP (CP-16-17)

°C/W

ESD CAUTION
