8 / 28 page  AD8224 Rev. B | Page 8 of 28 VS + = 5 V, VS− = 0 V, VREF = 2.5 V, TA = 25°C, G = 1, RL = 2 kΩ1, unless otherwise noted. Table 6 displays the specifications for the dynamic performance of each individual instrumentation amplifier. Table 6. Dynamic Performance of Each Individual Amplifier—Single-Ended Output Configuration, VS = +5 V A Grade B Grade Parameter Conditions Min Typ Max Min Typ Max Unit DYNAMIC RESPONSE Small Signal Bandwidth −3 dB G = 1 1500 1500 kHz G = 10 800 800 kHz G = 100 120 120 kHz G =1000 14 14 kHz Settling Time 0.01% G = 1 ΔVO = 3 V step 2.5 2.5 μs G = 10 ΔVO = 4 V step 2.5 2.5 μs G = 100 ΔVO = 4 V step 7.5 7.5 μs G =1000 ΔVO = 4 V step 60 60 μs Settling Time 0.001% G = 1 ΔVO = 3 V step 3.5 3.5 μs G = 10 ΔVO = 4 V step 3.5 3.5 μs G = 100 ΔVO = 4 V step 8.5 8.5 μs G =1000 ΔVO = 4 V step 75 75 μs Slew Rate G = 1 to 100 2 2 V/μs 1 When the output sinks more than 4 mA, use a 47 pF capacitor in parallel with the load to prevent ringing. Otherwise, use a larger load, such as 10 kΩ. VS + = 5 V, VS− = 0 V, VREF = 2.5 V, TA = 25°C, G = 1, RL = 2 kΩ1 unless otherwise noted. Table 7 displays the specifications for the dynamic performance of both amplifiers when used in the differential output configuration shown in Figure 63. Table 7. Dynamic Performance of Both Amplifiers—Differential Output Configuration2, VS = +5 V A Grade B Grade Parameter Conditions Min Typ Max Min Typ Max Unit DYNAMIC RESPONSE Small Signal Bandwidth −3 dB G = 1 1500 1500 kHz G = 10 800 800 kHz G = 100 120 120 kHz G =1000 14 14 kHz Settling Time 0.01% G = 1 ΔVO = 3 V step 2.5 2.5 μs G = 10 ΔVO = 4 V step 2.5 2.5 μs G = 100 ΔVO = 4 V step 7.5 7.5 μs G =1000 ΔVO = 4 V step 60 60 μs Settling Time 0.001% G = 1 ΔVO = 3 V step 3.5 3.5 μs G = 10 ΔVO = 4 V step 3.5 3.5 μs G = 100 ΔVO = 4 V step 8.5 8.5 μs G =1000 ΔVO = 4 V step 75 75 μs Slew Rate G = 1 to 100 2 2 V/μs 1 When the output sinks more than 4 mA, use a 47 pF capacitor in parallel with the load to prevent ringing. Otherwise, use a larger load, such as 10 kΩ. 2 Refers to the differential configuration shown in . Figure 63 |
|
